Liv Devote Advanced Pro

Liv Devote Advanced Pro
Please select options Unavailable

Details

The Devote Advanced Pro was born and bred for gravel race glory. With its lightweight yet robust construction and performance-driven design, it’s ready to carry speed across county lines, above tree lines, and over finish lines.

Ultralight Agility
- An ultralight Advanced-grade composite frame and new Advanced SL-grade composite fork make for snappy acceleration, while internal cable routing streamlines your cockpit and makes room for your must-have accessories. And the redesigned geometry puts you in a more aggressive position, increases traction and stability, and allows more control at speed and on descents.

Superior Compliance and Control
- The Contact SLR XR D-Fuse handlebar features a 5-degree back sweep and flare drop for comfortable and ergonomic grip. The Contact SLR D-Fuse seatpost can be swapped out for a 30.9mm or 27.2mm round seatpost. These proprietary D-Fuse components absorb bumps and reduce vibrations, ensuring less fatigue and more fun on those epic rides.

Unmatched Versatility
- Adapt to the route with the flip chip – dropout, which lets you adjust your wheelbase length and rear-wheel tire clearance. Go shorter for responsive handling and quick acceleration. Go longer for added stability plus clearance for larger tires and extra traction. Plus, the integrated down tube storage lets you stash a multi-tool or extra fuel, so nothing’s slowing you down.

bike diagram with measurements referenced in table that follows

Sizes:
SizeX-SmallSmallMedium
Geo Setting SHORT | LONG SHORT | LONG SHORT | LONG
A Seat Tube Length (mm) 390 420 465
B Seat Tube Angle 74.5° | 74.4° 74.5° | 74.4° 74.5° | 74.4°
C Top Tube Length (mm) 525 | 525 535 | 535 545 | 545
D Head Tube Length (mm) 90 110 140
E Head Tube Angle 70.0° | 69.9° 70.5° | 70.4° 71.0° | 70.9°
F Fork Rake (mm) 50 50 50
G Trail (mm) 78.4 | 82 75 | 78.5 71.6 | 75.1
H Wheelbase (mm) 1012 | 1022 1019 | 1029 1026 | 1036
I Chain Stay Length (mm) 425 | 435 425 | 435 425 | 435
J Bottom Bracket Drop (mm) 80 | 81 80 | 81 80 | 81
K Stack (mm) 523 | 524 544 | 545 574 | 575
L Reach (mm) 380 | 379 384 | 383 386 | 385
M Stand Over Height (mm) 681 | 688 708 | 715 748 | 755
N Handlebar Width (mm) 400 400 420
O Stem Length (mm) 50 60 70
P Crank Length (mm) 165 170 172.5
Sizes:
SizeX-SmallSmallMediumLarge
Rider Height (cm) 150–163 cm 158–169 cm 164–175 cm 170–181 cm

Specs

Frame Advanced-grade composite, 12x142mm thru-axle, flat mount disc, flip chip – dropout, integrated down tube storage, integrated cable routing
Fork Advanced SL-grade composite, full-composite OverDrive steerer, 12mm thru-axle, flat mount disc, FSA stainless upper/lower bearings
Rims Giant CXR 1, [F] 35mm, [R] 35mm
Hubs [F] Giant AR alloy, CenterLock, 12mm thru-axle, [R] Giant AR alloy, DT350 36t ratchet system, CenterLock, 12mm thru-axle
Spokes Sapim CX-Ray
Tires CADEX GX, 700x40c, foldable, tubeless
Bottom Bracket SRAM DUB, press fit
Crankset SRAM Force D2 DUB, 30/43, XS: 165mm, S: 170mm, M: 172.5mm, L: 172.5mm
Shifters SRAM Force AXS E1, 2x12
Front Derailleur SRAM Force AXS E1
Rear Derailleur SRAM Force AXS D2
Cassette/Freewheel SRAM Force E1, 12-speed, 10x36
Chain SRAM Force E1
Brakes SRAM Force AXS E1 hydraulic, SRAM CenterLine rotors, [F]160mm, [R]160mm
Brake Levers SRAM Force AXS E1 hydraulic
Handlebars Giant Contact SLR XR D-Fuse, 31.8mm, 5-degree back sweep, flare drop, XS: 400mm, S: 400mm, M: 420mm, L: 420mm
Tape/Grips Liv All Condition
Stem Giant Contact AeroLight, -10 degree, XS: 50mm, S: 60mm, M: 70mm, L: 80mm
Seatpost Giant D-Fuse SLR, composite, -5/+15mm offset
Saddle Liv Grit SL
Pedals Sold Separately

* Subject to change without notice.
